3" 4" 5" 6" Silicon Oil Glycerine Oil Filled Ss 304 Stainless Steel Bimetal Thermometer

Basic Info.

Model NO.	LFI series
Usage	Industrial
Display	Pointer
Material	Bimetallic
Hygrometer Type	Bimetal Thermometer
Experience	Founded in 2005
Measuring Medium	Temperature
Field	Pipeline,Surface,Industrial,Oil,Chemical
OEM/ODM	Welcomed
Design Principle	Pipeline,Surface,Industrial,Oil,Chemical,Power Sta
Stem Od	6.35mm
Strip	Bimetallic Strip
Fully Mechanical	No Electricity or Wiring
Connection	1/2"NPT
Lens	Glass
MOQ	100 Pieces
Enclosure Rating	IP65
Thermometer Standard	ASME B40.200; En 13190
Mounting	Bottom Connection
Installation	Easily Installed and Maintained
Transport Package	Cartons or Customized
Specification	Dial3", 4", 5", and 6" or customized
Trademark	QualityWell
Origin	Shanghai, China
HS Code	90251910
Production Capacity	6000pieces/Day

Packaging & Delivery

Package Size 16.00cm * 12.00cm * 6.00cm Package Gross Weight 0.500kg

Product Description

3" 4" 5" 6" Silicon Oil Glycerine Oil Filled Ss 304 Stainless Steel Bimetal Thermometer

Dial Size	3",4",5", and 6" available, aluminum material, dish shape
Case	SS 304 stainless steel
Lens	Glass standard, Shatterproof Glass Len Is Available
Bezel	SS 304 stainless steel, hermetically sealed or detachable
Pointer	Aluminum, painted black
Movement	Bi-metallic coil imported from US
Stem OD	6.35mm
Stem Length	Customized
Connection	Bottom Connection
Thread	1/2"NPT
Accuracy	+/-1.5% full scale standard; +/-1% full Scale Available
Range	From -80 C/0 C And 0 C/550 C (customized)
Fillable	Silicon oil or glycerine available
Packaging	Shakeproof
Enclosure Rating	IP65
Standard	ASME B40.200-2008, EN13190:2001
Field	Pipeline,surface,industrial,oil,chemical,power station,marine,etc.

3" 4" 5" 6" Silicon Oil Glycerine Oil Filled Ss 304 Stainless Steel Bimetal Thermometer

Q:Are you able to develop customized solutions for non-standard applications?
A:Yes, we can. We have a strong professional developing team
Q:Can I receive the dial layout before you produce the instruments?
A:Yes, we can send the dial proof for customer's approval within 1 week
Q:Are you able to face urgencies by offering a shorter delivery time?
A:Yes, we are a manufacturer, we can offer a shorter delivery time depends on the customer's particular requests
Q:Are you able to supply technical drawings and data sheets of your instruments?
A:Yes, we can supply upon customer's request, please contact with our sales
Q:Do you usually apply an MOQ or can you supply also small quantities?
A:Yes, different item different MOQ, except OEM item, please contact our sales for your order code
Q:Is it necessary an expert for the installation of your instruments?
A:No, user can finish the installation easily following our specific product manual
Q:Do you organize on site training courses in my country?
A:At present we don't have the plan to organize the training courses in your country. But we may offer the information or the documents which you need, include the video
Q:What is your discount policy?
A:We usually give discount according to the difference of QTY, Delivery, the payment term, and the amount and so on
Q:What are the benefits of buying your instruments, as the Chinese products are usually considered low quality?
A:I think it is not right to consider all Chinese products are low quality. Now the quality of Made in China is better and better. You may see Made in China because the market needs it. And if you buy our products , you may find you buy the high quality with the reasonable price and we also offer the good service
Q:Can I receive a reference list of your main customers?
A:Sorry the customers information are the company property. We are not able to give you the list. Anyway, our main customers are located in North America and Europe, some of them are very famous, and we have over 20 years of industrial experience.
